L90 Series butterfly valves
Product Description
FEATURES AND BENEFITS:
• Metal to metal sealing
• Triple eccentric quarter-turn design
• Torque seated
• Bi-directional tight shutoff
• Zero leakage
• Non-rubbing seating
• Inherently fire safe and fire tested
TYPICAL APPLICATIONS:
• Process fluids
• Hydrocarbons
• Steam/Geothermal steam
• Hot gas/Sour gas (NACE)
• Oxygen, Hydrogen
• Blow down
• Sulfur recovery
• Acid, Caustic, Chloride
• Abrasive service
| Valve Series | Pressure rating | Size range | TemperatureºC | Materials | Connection Type | Standards |
|---|---|---|---|---|---|---|
| L90 Series | 150LB~2500LB | DN50～1500 | -196～+800 | LCB、 LC3、WC6、WC9 | Butt weld |
ANSI B16.25 DIN 2559 |
